Below is a clear, step-by-step guide to help you install your side body skirts safely and correctly. Please read through all instructions before starting.

PDF Side Skirt Installation

PDF Side Skirt Installation For GR 86

Step 1: Gather Your Tools and Materials

• Included: Self-tapping screws, double-sided mounting tape
• Recommended: Adhesion promoter, electric drill, drill bits, clean cloth, mild cleaning solution or isopropyl alcohol, masking tape (optional)
• Note: Two-person installation is recommended for safety and accuracy.

Step 2: Prepare the Vehicle

• Park on a level surface and engage the parking brake.
• Raise the vehicle with a jack or lift for easier access.

Step 3: Clean the Rocker Panels

• Use a mild cleaning solution or isopropyl alcohol to remove all dirt and residue.
• Ensure the surface is completely dry before moving on.

Step 4: Test-Fit the Side Skirts

• Hold each side skirt against the rocker panel to check alignment.
• Make any necessary adjustments to ensure a proper fit.

Step 5: Apply Adhesion Promoter

• Lightly coat the areas on the side skirt where the double-sided tape will be placed.
• Use sparingly to avoid damaging the paint.

Step 6: Attach the Double-Sided Mounting Tape

• Cut the tape to the needed lengths.
• Press it firmly onto the prepared areas on the back of the side skirt.
• Keep the tape backing on until you are ready to secure the skirt to the vehicle.

Step 7: Position and Align the Side Skirts

• Carefully align the side skirt with the rocker panel.
• Check alignment from front to back and top to bottom before securing.

Step 8: Secure the Tape

• Peel away a small portion of the tape backing.
• Press the exposed tape firmly against the rocker panel.
• Continue peeling and pressing until the entire length is secured.

Step 9: (Optional) Apply Adhesion Promoter to the Car

• For an even stronger bond, apply a thin layer of adhesion promoter to the rocker panel itself.
• Use a minimal amount.

Step 10: Drill and Install Self-Tapping Screws

• Pre-drill pilot holes if needed, then insert the self-tapping screws.
• Space them evenly along the underside of the skirt.
• Avoid overtightening to prevent damage.

Perform a Final Inspection

• Check that the side skirt sits flush against the rocker panel.
• Press along the taped areas if you notice any gaps.

Post-Installation Guidelines

• Do not wash the car or drive at high speeds for 24 hours to allow the adhesive to cure.
• Be careful when entering or exiting the vehicle—avoid stepping on the side skirts.

Congratulations! Your side skirts are now installed. By following these guidelines, you’ll ensure a secure, long-lasting upgrade that enhances both the look and performance of your vehicle. If you have any questions or concerns, feel free to reach out to our support team.
